Unlock maximum precision and eliminate position loss with the high-performance SOYA NEMA 24 series closed-loop hybrid stepper motor. Featuring a standard 60mm square frame size and impressive 4.0N.m torque output, this closed-loop system integrates a high-resolution encoder to deliver flawless position tracking, higher usable torque, and lower thermal output. Perfect for demanding industrial applications requiring high load holding, dynamic acceleration, and ultra-reliable positioning accuracy.
Integrated high-resolution encoder provides real-time position feedback, completely eliminating the risk of lost steps under sudden load changes.
Optimized magnetic design delivers a massive 4.0N.m holding torque, ensuring extreme load rigidity across extensive, high-load cycles.
Advanced current control adjusts dynamically based on the actual load, drastically reducing motor temperature and energy consumption.
Suppresses low-speed resonance and vibrations, ensuring ultra-smooth motion and whisper-quiet operation in industrial environments.
| Model No. | Step Angle (°) | Current (A) | Resistance (Ω) | Inductance (mH) | Holding Torque (N·m) | Motor Length (mm) | Encoder Res. (PPR) | Weight (kg) |
|---|---|---|---|---|---|---|---|---|
| 60HSE3N-D25 | 1.8 | 5.0 | 0.45 ±10% | 1.8 ±20% | 4.0 | 100 | 1000 | 1.75 |
